XTOOL D8S - Professional Diagnostic Scanner (Version 2026)

The Evolution of the D8: Faster, More Memory and Total Connectivity

Full System Diagnostics | ECU Coding | Topology Mapping | 3 Years of Free Updates

🚀 Why choose the XTOOL D8S?

The D8S isn't just an upgrade; it's a complete re-engineering of the successful XTOOL D8. Now with superior hardware for a seamless workflow:

  • ✅ Native Protocols: Integrated support for CAN-FD (GM 2020+) and DoIP (BMW/Land Rover) without extra adapters.
  • ✅ Powerful Hardware: Android 10, 4GB RAM + 64GB ROM and 10,000 mAh Battery.
  • ✅ Topology Mapping: Visualize the vehicle's entire network in a graphical tree to detect faults instantly.
  • ✅ FCA AutoAuth: Security Gateway Access for Chrysler, Jeep, Dodge, Fiat (2018+).

📋 Official Coverage Lists

Check exact compatibility by make and model before purchasing:

💡 Note: The green button opens the direct odometer adjustment list. The blue button takes you to the XTOOL website (there, select "D8S" and then "Diagnosis").

🌐 Module Topology Mapping

Take your diagnostics to dealership level. The D8S scans all modules and generates a visual map of the vehicle's communication network .

🔹 Visualize the problem: Quickly identify which modules are faulty (red) and which are working (green).
🔹 Save time: Understand the communication structure without reading complex manual diagrams.
*Note: Available for GM, Ford, Toyota, Honda, Nissan, Mazda, BMW, Benz, Hyundai, Kia, etc.

💻 ECU Coding (VAG)

Performs online coding for VW, Audi and Skoda vehicles.

  • Pair new components after replacement.
  • Flash Hidden Functions.
  • Deactivate annoying functions (Start/Stop, seatbelt alarms).

*Note: D8S performs Coding, not ECU Reprogramming (J2534).

🔧 Installation of Programmable Modules (PMI)

Essential function for Ford, Lincoln and Mazda .

  • It allows you to copy the data from the original module (ECU/TCU/ABS) and install it on the new or used replacement unit.
  • It simplifies computer replacement without the need for complex programming.

🛠️ OE-Level Diagnosis and Bidirectional Control

Diagnostics of all systems: Engine, Transmission, ABS, Airbag, SAS, TPMS, Chassis, Body, HVAC, etc. Code reading, 8-in-1 live data and freeze frame.

Active Test (Bidirectional Control): Sends commands to the actuators to verify their operation without disassembling parts.

  • 🔹 Injector test (Balance/Humming)
  • 🔹 Activate fuel pump
  • 🔹 Turn on radiator fan
  • 🔹 Raise/Lower windows and locks
  • 🔹 Activate A/C compressor
  • 🔹 EVAP tests

🧰 More than 38 Special Service Functions

Oil Reset
ABS purging
Injector Coding
DPF Regeneration
SAS Adjustment
BMS Reset (Battery)
Accelerator Adaptation
TPMS Reset
EPB Brake
Key Programming
Air Suspension
Learning Box (Gear)
Windows Initialization
AFS lighthouses
Power Balance
Box Pairing

🔑 Advanced IMMO Functions / Keys

The D8S is not just for diagnostics. It allows you to add new keys, deactivate lost keys, and read PIN codes on many vehicles.

Compatible with XTOOL accessories (sold separately):

  • KC100: For VW/Audi 4th/5th Gen and BMW.
  • KC501: For programming Mercedes Benz infrared keys.
  • KS01: For Toyota "All keys lost".
  • M821 / M822: Adapters for Mercedes and Toyota 8A.
  • XV100: Inspection videoscope.

Specifications and Package

  • 📱 Screen: 8-inch Touchscreen
  • 🧠 System: Android 10.0
  • 💾 Memory: 4GB RAM + 64GB ROM
  • 🔋 Battery: 10,000 mAh (Long lasting)
  • 📡 WiFi: 2.4Ghz and 5Ghz

Box Contents:

  • 1x XTOOL D8S Tablet
  • 1x Adapter cable kit
  • 1x OBDII Main Cable
  • 1x Charger and USB cable
  • 1x Rigid carrying case

🎁 BONUS: 3 Years of FREE Software Updates

Original XTOOL product distributed by OBD Master.
